MODEL

45

65

65XL

75

85

85XL

Nominal Capacity

4.0cu.m

6.0cu.m

7.0cu.m

7.5cu.m

8cu.m

9cu.m

Geometric Volume

7.8cu.m

10.58cu.m

12.1cu.m

13.06cu.m

14.2cu.m

14.6cu.m

Filling Ratio

51%

57%

58%

57%

59%

61%

Rotation Speed

0 -14rpm

0 -14rpm

0 -14rpm

0 -14rpm

0 -14rpm

0 -14rpm

Diameter

2200mm

2200mm

2200mm

2200mm

2200mm

2200mm

No. of Rollers

2

2

2

2

2

4

Water Pump Outlet

400 ltr/min

400 ltr/min

400 ltr/min

400 ltr/min

400 ltr/min

560 ltr/min

Water Pump Pressure

3.5bar

3.5bar

3.5bar

3.5bar

3.5bar

4bar

Water Meter Scale

0-450ltr

0-450ltr

0-450ltr

0-450ltr

0-450ltr

0-600ltr

Water Tank Capacity

450ltr

450ltr

450ltr

450ltr

450ltr

600ltr

Shell Thickness

3-4-5-6mm

3-4-5-6mm

3-4-5-6mm

3-4-5-6mm

4 - 6mm

4-5-6-8mm

Engine Power

35kW

52kW

52kW

52kW

81/PTO kW

81kW

Frame Length [A]

3896mm

4560mm

5016mm

5220mm

5510/5310 mm

6120mm

Max. Length [B]

4936mm

5634mm

6090mm

6286mm

6500/6300mm

7400mm

Over Hang [C]

1040mm

1074mm

1074mm

1080mm

1150mm

1240mm

Max Height [H]

2295mm

2515mm

2575mm

2615mm

2680mm

2735mm

Max Width

2300mm

2300mm

2300mm

2300mm

2450/ 2300mm

2400mm

Total Weight

3060kg

3640kg

3940kg

4090kg

4450/3820kg

5280kg
